Keensert Installation
Specifications & Charts
How to identify and verify the specifications that determine Keensert installation requirements, including thread size, insert length, and receiving-hole diameter.
What specifications are needed to install a Keensert?
Installing a Keensert requires the insert series and size, internal and external thread size, insert length, receiving-hole diameter, tap and countersink requirements, installation depth, locking-key requirements, and the parent material. These are found on the applicable engineering drawing or the insert manufacturer's installation documentation.
Specifications That Determine Installation
- Internal thread size — the finished thread the fastener will engage after installation.
- External thread — the thread the insert itself cuts into or engages within the tapped hole.
- Insert length — determines the minimum depth the receiving hole must be prepared to.
- Receiving-hole diameter — the drilled hole diameter the insert is designed to be installed into.
- Tap requirements — the specific tap used to cut the external thread for that insert size.
- Countersink requirements — entry geometry required for some installations, where applicable.
- Installation depth — how far the insert body must be seated below or at the surface.
- Locking-key requirements — the setting method and tooling for that insert's locking keys.
- Parent material — aluminum, magnesium, steel, and other materials affect tooling and installation method selection.
- Applicable engineering drawing — the controlling document for the specific application.
- Manufacturer documentation — the insert manufacturer's installation instructions for the exact series and size being used.
Specification Selection Guide
| Specification | Why It Matters | Where to Verify |
|---|---|---|
| Insert series | Determines applicable installation requirements | Manufacturer data / engineering drawing |
| Internal thread | Determines finished fastener interface | Part specification |
| External thread | Determines tapped receiving hole | Manufacturer data |
| Insert length | Determines required hole depth | Part specification |
| Drill requirement | Controls hole preparation | Manufacturer installation data |
| Tap requirement | Creates insert receiving thread | Manufacturer installation data |
| Countersink | Provides required entry geometry where applicable | Manufacturer instructions |
| Installation depth | Affects finished assembly | Engineering requirements |
This table is a reference for what to check, not a dimensional chart. Where exact dimensions are required, refer to the applicable insert manufacturer's technical data and the governing engineering documentation rather than a reproduced or estimated value.
Keensert Installation Specifications FAQ
Send Us Your Keensert Specification
Provide your engineering drawing or the insert manufacturer's specification and our team will confirm installation requirements and provide a quote.
